What is mapping load and ApplyMap?

Hi, Check this example for Mapping load and Apply Map functions. Mapping load is used for load the mapping table where as Apply Map is used for mapping the Mapped table to another table for more see the example below.

.

Then, what is mapping load in qlik sense?

Mapping to the load statement tells Qlikview that a table is Mapped with another. A mapping table can have 2 columns- the lookup value and the mapping value. Mapping Tables are temporary tables as they are automatically removed from the data model by the end of the execution of the script.

Secondly, how many fields are in a mapping table? QlikView Mapping Load Statement Typically, a mapping table has two columns, first containing values for comparison (as a reference point) and second containing the resultant or desired values based on the comparison.

Likewise, what is apply map?

The ApplyMap script function is used for mapping the output of an expression to a previously loaded mapping table. If stated, this value will be used as a default value if the mapping table does not contain a matching value for expression . If not stated, the value of expression will be returned as is.

What is the use of Crosstable prefix in QlikView load script?

Crosstable. The crosstable prefix is used to turn a cross table into a straight table, that is, a wide table with many columns is turned into a tall table, with the column headings being placed into a single attribute column. The field that contains the attribute values. The field that contains the data values.

Related Question Answers

What is mapping table?

Mapping table is a table, which is created to map the column values between two tables. It is also called a Lookup table, which is only used to look for a related value from some other table.

What is Section access in QlikView?

Section Access is a QlikView feature that is used to control the security of an application. It is basically a part of the load script where you can define an authorization table, i.e. a table where you define who gets to see what. (In a real application, the authorization table is not visible in the data model.)

What is SQL Server Mapping?

A SQL Map enables you to publish data service functions as SQL objects (which are created when you specify the mapping). Using SQL Maps, you can expose data services modeled in Oracle Data Service Integrator as relational data sources.

What is IntervalMatch QlikView?

The Interval Match is one of the functions in QlikView that can be used to match a numeric value in a single table, such as date, timestamp, score, percent or any number, to an interval or duration in a second table. The IntervalMatch function discreet data to one or more dimensions that are changing over time.

What is Peek function in QlikView?

The peek() function in QlikView is used to fetch the value of a field from a previous record and use it in calculations.

What is incremental load in QlikView?

Incremental load is defined as the activity of loading only new or updated records from the database into an established QVD. Incremental loads are useful because they run very efficiently when compared to full loads, particularly so for large data sets.

What is set analysis in QlikView?

Set Analysis in QlikView – simplified! Set analysis predefines the SET OF DATA that our charts / tables use. So, using a Set Expression, we can tell our object (chart / table) to display values corresponding to various sets of data (e.g. a pre-defined time-period, geographic region, product lines etc.).

What is link table in QlikView?

Link table is used in a data model when you have multiple fact tables to handle. Another way to handle multiple fact table is concatenate, so you can find some post on link table vs concatenate, Concatenate or Link Table? Get started with developing qlik datamodels.

What is subfield in QlikView?

The Subfield function is the most loving function of QlikView because it automatically removes duplicate records generated by the function (Load and DISTINCT statement). This function lies between the string and text function category. The Subfield function returns the substring from the string or variable.

What is a cross table?

A cross table is a two-way table consisting of columns and rows. It is also known as a pivot table or a multi-dimensional table. Cross tables can also be used to determine whether there is a relation between the row variable and the column variable or not.

What is cross table in QlikView?

A cross table is a common type of table featuring a matrix of values between two orthogonal lists of header data. If this table is simply loaded into QlikView, the result will be one field for Year and one field for each of the months.

What is generic load in QlikView?

The Generic Load. There are a number of prefixes in QlikView, that help you load and transform data. Enter the Generic prefix. It converts the data to a structure where each attribute is placed in a field of its own. Another way to express it is to say that it takes field values and converts these to field names.
